Current Electricity Class 12 Notes Chapter 3
Current Electricity Class 12 Notes
1. The directed rate of flow of electric charge through any cross-section of a conductor is known as electric current.
If ∆Q charge flows in time ∆t, then current at any time t is
NOTE: Current is a scalar quantity.
I is in the direction of flow of positive charge and opposite to the direction of flow of negative charge.
SI unit of current is ampere and is represented by A.
2. The current density at a point in a conductor is the ratio of the current at that point in the conductor to the area of cross-section of the conductor at that point provided the area is held normal to the direction of flow of current.
NOTE: Current density is a vector quantity.
Notes Of Current Electricity Class 12
3. Flow of Electric Charge in Metallic Conductors Among the solids, all metals are good conductors of electricity. The cause of conductance is free electrons.
In Case of a Solid Conductor (i.e. Cu, Fe, Ag, etc) atoms are tightly bound to each other. There are large number of free electrons in them.
In Case of a Liquid Conductor Like electrolytic solution, there are positive and negative charged ions which can move on applying electric field.
Electric Current Class 12 Notes
4. Drift Velocity It is defined as the average velocity with which the free electrons move towards the positive end of a conductor under the influence of an external electric field applied.
Class 12 Physics Chapter 3 Current Electricity Notes
5. Electric current in terms of drift velocity
6. Current density at any point of conductor,
j = nevd
where, j is a vector quantity.
7. Mobility The ratio of drift velocity of electrons and the applied electric field is known as mobility.
Electric Current Class 12
8. Ohm’s Law At constant temperature, the potential difference V across the ends of a given metallic wire (conductor) in an circuit (electric) is directly proportional to the current flowing through it.
The variation of current w.r.t. applied potential difference is shown with the help of following graph.
V = IR
where, R = resistance of conductor
No effect of V and I on R because as V increase, I increase but R remains the same.
Current Electricity Class 12 Short Notes
9. Resistance of a Conductor Mathematically, it is the ratio of potential difference applied across the ends of conductor to the current flowing through it.
=> R = V/I
SI unit is ohm (Ω).
Resistance can also be written as,
R =ρ L/A
where, L = length of the conductor, A = area of cross-section and ρ = constant, known as resistivity of the material. It depends upon nature of the material.
Physics Current Electricity Class 12 Notes
10. Relationship between resistivity and relaxation time
12. Temperature Coefficient of resistance is given by
13. Conductivity It is defined as the reciprocal of resistivity of a conductor.
It is expressed as, σ = 1/ρ
SI unit is mho per metre (Ω-1/ m).
Electric Current Notes
14. Superconductivity The resistivity of certain metal or alloy drops to zero when they are cooled below a certain temperature is called superconductivity. It was observed by Prof. Kamerlingh in 1911.
Current And Electricity Class 12
15. Relationship between current density (j), electric field (E)and conductivity (σ ) is
j = σ E
Notes On Current Electricity
16. Some Important Units
17. If a conductor is stretched or compresses to n times of original length, then
l’ = nl => R’ = n2R
where, R’ = new resistance and R = original resistance.
Current Electricity Class 12 Ncert Notes
18. Colour Code of Resistance The colour code on carbon resistor remains in the form of coaxial rings.
The first band represents the first significant figure, second band represents second significant figure and third band represents multiplier (i.e. power of ten). The fourth band represents tolerance.
19. Combinations of Resistance There are two types of resistance combinations.
(i) Series Combination In this combination, different resistances are connected end to end.
Equivalent resistance can be obtained as the formula,
NOTE: The total resistance in the series combination is more than the greatest resistance in the circuit.
(ii) Parallel Combination In this combination, first end of all the resistances are connected to one point and last end of all the resistances are connected to other point. Equivalent resistance can be obtained by the formula
NOTE: The total resistance in parallel combination is less than the least resistance of the circuit.
20. If n identical resistors each of resistance r are connected in
(i) series combination, Req = nr
(ii) parallel combination, Req = r/n
